Portable Pencil Hardness Tester Paint Testing Equipment
Standard:
GB/T6739-2006,ASTMD3363,ISO15184,BS3900-E19,ECCA-T4/1,JIS,CNS
Features:
Coating hardness is the necessary measurement for the performance
of coatings. This instrument applied the pencil scratch method. It
is a fast and economical way to determine the film hardness using
the drawing lead core or the pencil core.
Description:
The Pencil Hardness Tester applies mechanical measurement. Keep
three point touch the coating (two wheel, a pencil core), and a 45
degree angle between pencil and test surface. Push the instrument
sliding, pencil draws the corresponding track in the coating. In
the change of different pencil marks, the hardness value of the
film can be determined.Paint Testing Equipment
Specification:
| Load Weight | 1000g /750g /500g |
| Measurement Angle | 45°(Between Pencil and Measured Surface) |
| Three Touch Points | Two Wheels, A Pencil Core |
| Scratch Speed | About 1 mm/s |
| Standard Configuration | Pencil Hardness Tester |
| 1000g Weight |
| 750g Weight |
| 500g Weight |
| Pencils (6B-6H) |
| Eraser |
| Knife |
| Horizontal Pad Block |
| Sandpape |
About Us:
260 workers, 25000 ㎡ non-dust workshop, 16 years experience, SGS &
INTERTEK certificated, one hour reach Tianjin port, this is how we
keep good quality and competitive prices for global valued
customers.Paint Testing Equipment
Our main products cover Universal testing machine, Compression
testing machine, Soil,Concrete,Cement Mortar,Aggregates Rocks,
Asphalt Bitumen, NDT,Pavement ,Paint,Ceramics,Drilling Fluids,
Geotextiles, Textiles, Environmental,General Equipment,Universal
Testing Equipment.BTUTEST is exporting its products to more than 60
countries by offering its services through its authorized
distributors and representatives.Paint Testing Equipment
Our main customers are private and research testing laboratories,
road and general contractors, concrete and cement manufacturers,
asphalt manufacturers, government authorities, ministries,
engineers, consultants and re-seller. We also cooperate with
accredited research centers and the most important universities in
the world.we can supply more top quality product and service for
more customer’s.
Our Advantage:
Q1: What is your warranty ?
A: 12 months product warranty, but lifetime for services.
Q2: How-to video provided ?
A: Yes. If required, our engineers will record a specialized how-to
video for you.
Q3: Are your company a trading one or a factory?
A: Yes, we are a manufactured factory & trade (integration).16
years focusing on test instruments field. warmly welcome to visit
our plant (factory), we also support OEM and ODM.
Q4: After an order is placed, when to deliver?
A: Generally about 10 days. If we have inventory, we can arrange
shipment within 7 days. Please be aware that our production lead
times depend on specific items and item quantities.
Q5: What about the after-sales service and product’s quality?
A: 12 months warranty. After the warranty, the professional
after-sale service team will provide perfect technical support. And
help the customer solve problems encountered while using our
product, handles problems and complaints professionally and timely.
Each instruments must be carried out 100% quality examination and
test when shipping and delivery goods.
Q6: what about the packing of equipment?
A: Covered with air bubble film before put the machine into the
standard exporting wooden case, which not only has good shock
absorption, impact resistance, heat SSO has the advantages of
nontoxic, odorless, moisture corrosion, good transparency etc.
